Description
ENGINE:
- Engine Type: Single cylinder, liquid-cooled, 4-stroke, SOHC, 4-valve
- Displacement: 590 cc
- Transmission: CVT
- Maximum Power: 30 kW @ 6750 rpm
- Maximum Torque: 49 Nm @ 5250 rpm
- Compression Ratio: 10.68:1
- Fuel Supply: EFI
- Ignition: ECU
DIMENSIONS & WEIGHT:
- Length x Width x Height: 2235 x 1180 x 1390 mm
- Wheelbase: 1480 mm
- Seat Height: 530 mm
- Ground Clearance: 270 mm
- Weight: 400 kg
- Payload Capacity: 235 kg
- Towing Capacity: 300 kg
- Fuel Capacity: 18 L
RIDE:
- Drive: Switchable 2WD/4WD
- Brake: Four-wheel brake (CBS) + rear wheel parking brake
- Suspension:
- Front/Rear: Double A-arm, independent suspension
- Shock Absorber:
- Front/Rear: Coil spring + oil damping, preload adjustable
- Rim:
- Front: 12×6.0, cast aluminum
- Rear: 12×7.5, cast aluminum
