Description
ENGINE:
- Engine Type: V-Twin, liquid-cooled, 4-stroke, SOHC, 8-valve
- Displacement: 800 cc
- Max Power: 75 HP @ 7500 RPM
- Max Torque: 52 lb-ft @ 5500 RPM
- Fuel System: Bosch® EFI
- Cooling System: Liquid cooled
- Drive: 2WD / 4WD / 4WD lock
- Transmission: CVT (P/R/N/H/L)
- Starter: Electric
CHASSIS:
- Suspension:
- Front: High clearance A-arm independent
- Rear: Trailing arm independent
- Wheels: Front/Rear: 14” cast aluminum
- Tires:
- Front: 26” x 8” x R14
- Rear: 26” x 10” x R14
- Shocks: Front/Rear: Spring pre-load adjustable, oil damped
- Braking: Front/Rear: Hydraulic disc with parking brake
- Wheel Travel: Front/Rear: 9” / 9”
DIMENSIONS:
- Length x Width x Height: 2445 x 1264 x 1450 mm
- Wheelbase: 1480 mm
- Curb Weight: 465 kg
- Ground Clearance: 285 mm
- Fuel Tank Capacity: 26 L
- Rack Capacity: Front/Rear: 45kg/90kg
- Seat Height: 950 mm
